gnuplot demo script: smooth.dem

autogenerated by webify.pl on Fri Oct 28 21:05:37 2016
gnuplot version gnuplot 5.0 patchlevel 5
bin(x, s) = s*int(x/s)

set zeroaxis
set style data points

# Uniform
set title "Uniform Distribution"
set key top right
set boxwidth 0.05
plot [-0.1:1.1][-0.4:1.5] "random-points" u 1:(0.25*rand(0)-.35) t '', \
     "" u (bin($1,0.05)):(20/300.) smooth freq t 'smooth frequency' w boxes, \
     "" u 1:(1/300.) smooth cumulative t 'smooth cumulative'

Click here for minimal script to generate this plot





# Normal
set title "Normal Distribution"
set key top left
set boxwidth 0.05
plot "random-points" u 2:(0.25*rand(0)-.35) t '', \
     "" u (bin($2,0.05)):(20/300.) smooth freq t 'smooth frequency' w boxes, \
     "" u 2:(1/300.) smooth cumulative t 'smooth cumulative'

Click here for minimal script to generate this plot





# Lognormal
set title "Lognormal Distribution"
set key top right
set boxwidth 0.1
plot [0:] "random-points" u 3:(0.25*rand(0)-.35) t '', \
    "" u (bin($3,0.1)):(10/300.) smooth freq t 'smooth frequency' w boxes, \
    "" u 3:(1/300.) smooth cumul t 'smooth cumulative'

Click here for minimal script to generate this plot





# Mixed
set title "Mixed Distribution (Lognormal with shifted Gaussian)"
set key top right
set boxwidth 0.1
plot "random-points" u 4:(0.25*rand(0)-.35) t '', \
     "" u (bin($4,0.1)):(10/300.) smooth freq t 'smooth frequency' w boxes, \
     "" u 4:(1/300.) smooth cumul t 'smooth cumulative'

Click here for minimal script to generate this plot
